Publication GMSI10-UM005C-EN-P - May 2010
70 Specifications
Outputs
4-20mA Outputs
Buffered Outputs
Two isolated outputs
600 ohm max load
2 outputs; 1 per channel
Indicators
6 LEDs Module Status - red/green
Network Status - red/green
Channel 1 Status - yellow/red
Channel 2 Status - yellow/red
Setpoint Multiplier - yellow
Relay - red
Measurement Modes Normal (two independent channels)
Head-to-head
Radial cancel
Delta Time Buffer
Number of Records
Delta Time Interval
Trigger Mode
2048
1 to 3600 seconds
Relay on the XM-320 module is activated,
or by a trigger event (for example,
DeviceNet command from a controller or
host)
The data collected in the buffer is user
configurable.
Alarms
Number
Operators
Hysteresis
Startup Inhibit/Setpoint Multiplication
2 alarm and danger pairs
Greater than
Less than
Inside range
Outside range
User configurable in software
Period: 0 to 1092 minutes, adjustable in 0.1
minute increments
Inhibit/multiplication function: Multiply by
N (0 to 10, 0 = Disarm)
Relays
Number Single on-board relay, two sets of contacts -
DPDT (2 Form C)
Four additional relays when interconnected
to an XM-441 Expansion Relay module, or
Four virtual relays whose status can be
used by remote Control Systems or the
XM-440 Master Relay module
XM-320 Technical Specifications
Product Feature Specification
