Publication GMSI10-UM005C-EN-P - May 2010
42 Installing the XM-320 Position Module
Network Status (NS) Indicator
1 Normal condition when the module is not a slave to an XM-440, PLC, or other master device.
Channel 1 and Channel 2 Status Indicators
Setpoint Multiplier Indicator
Relay Indicator
Color State Description
No color Off Module is not online.
•
Module is autobauding.
•
No power is applied to the module, look at Module
Status LED.
Green Flashing Module is online (DeviceNet) but no connections are
currently established.
1
Solid Module is online with connections currently
established.
Red Flashing One or more I/O connections are in the timed-out state.
Solid Failed communications (duplicate MAC ID or Bus-off).
Color State Description
No Color Off
•
Normal operation within alarm limits on the channel.
•
No power applied to the module, look at Module
Status LED.
Yellow Solid An alert level alarm condition exists on the channel
(and no transducer fault or danger level alarm condition
exists).
Red Solid A danger level alarm condition exists on the channel
(and no transducer fault condition exists).
Flashing A transducer fault condition exists on the channel.
Color State Description
Yellow Off Setpoint multiplier is not in effect.
Solid Setpoint multiplier is in effect.
Color State Description
Red Off On-board relay is not activated.
Solid On-board relay is activated.
