Publication GMSI10-UM005C-EN-P - May 2010
Installing the XM-320 Position Module 21
7 TxD PC serial port, transmit data
8 RxD PC serial port, receive data
9 XRTN Circuit return for TxD and RxD
10 Chassis Connection to DIN rail ground spring or panel mounting hole
11 4-20mA 1 (+) 4-20mA output
600 ohm maximum load
12 4-20mA 1 (-)
13 Chassis Connection to DIN rail ground spring or panel mounting hole
14 Chassis Connection to DIN rail ground spring or panel mounting hole
15 Chassis Connection to DIN rail ground spring or panel mounting hole
16 Xducer 1 (-) Transducer 1 connection
17 Xducer 2 (-) Transducer 2 connection
18 Protected Output 1
(-) Short Circuit Protected Output 1, negative side
19 Protected Output 2
(-) Short Circuit Protected Output 2, negative side
20 No Connection
21 No Connection
22 Xducer V (-) Transducer power supply output, negative side
23 CAN_High DeviceNet bus connection, high differential (white wire)
24 CAN_Low DeviceNet bus connection, low differential (blue wire)
25 +24V Out Internally connected to 24V In (terminal 44)
Used to daisy chain power if XM modules are not plugged into
each other
26 DNet V (+) DeviceNet bus power input, positive side (red wire)
27 DNet V (-) DeviceNet bus power input, negative side (black wire)
28 24V Common Internally connected to 24V Common (terminals 43 and 45)
Used to daisy chain power if XM modules are not plugged into
each other
29 4-20mA 2 (+) 4-20mA output
600 ohm maximum load
30 4-20mA 2 (-)
31 Chassis Connection to DIN rail ground spring or panel mounting hole
32 Chassis Connection to DIN rail ground spring or panel mounting hole
33 Chassis Connection to DIN rail ground spring or panel mounting hole
34 Chassis Connection to DIN rail ground spring or panel mounting hole
35 Chassis Connection to DIN rail ground spring or panel mounting hole
36 Chassis Connection to DIN rail ground spring or panel mounting hole
37 Chassis Connection to DIN rail ground spring or panel mounting hole
38 Chassis Connection to DIN rail ground spring or panel mounting hole
Terminal Block Assignments
No. Name Description
