Publication GMSI10-UM005C-EN-P - May 2010
104 DeviceNet Objects
Services
1 Attributes can only be set while the device is in Program Mode. See the description of the Device Mode Object
for more information.
9 Get/Set Alarm Level BYTE Specifies what alarm
status values will cause
the relay to activate. 0 = Normal
1 = Alert
2 = Danger
3 = Disarm
4 = Xdcr Fault
5 = Module Fault
10 Get/Set Alarm Identifier
A EPATH Identifies the first alarm
status the relay monitors. See Parameter Object instances
6 to 10.
11 Get/Set Alarm Identifier
B EPATH Identifies the second
alarm status the relay
monitors. See Parameter Object instances
11 to 15.
12 Get/Set Logic USINT Indicates the number of
associated alarms that
must have a status value
specified by Alarm Level
in order to activate the
relay. 0 = Ignore Alarm Identifier B
and activate the relay based on
the status of Alarm Identifier
A.
1 = Activate the relay if the
status of either Alarm
Identifier A or B matches any
of the statuses specified by
Alarm Level.
2 = Activate the relay if the
status of both Alarm Identifier
A and B match any of the
statuses specified by Alarm
Level.
14 Get Relay Installed BOOL Indicates whether an
actual relay is associated
with this instance. 0 = Not installed
1 = Installed
Table C.36 Relay Object Instance Attributes
Attr ID
Access
Rule
Name Data Type Description Semantics
Table C.37 Relay Object Services
Service
Code
Class/Instance Usage Name Description
05
h
Class/Instance Reset Resets latched relay.
0E
h
Class/Instance Get_Attribute_Single Returns a single attribute.
10
h
Class/Instance Set_Attribute_Single
Sets a single attribute.
1
