Kinetix 300 and Kinetix 350 Drive Systems
Performance Specifications with Kinetix 300 (200V-class, single-phase) Drives (continued)
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient, and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Performance Specifications with Kinetix 300 (200V-class, three-phase) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient, and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Linear Motor
Speed, max
m/s (ft/s)
System Continuous
Stall Current
(1)
Amps 0-pk
(1) Values represent the range between no cooling (low value) and water cooling (high value).
System Continuous
Stall Force
(1)
N (lb)
System Peak
Stall Current
Amps 0-pk System Peak
Stall Force
N (lb) Linear Motor
Rated Output
(1)
kW
Kinetix 300 (2)
200V-class
Single-phase Drives
(2) Drives selected are for motors with no cooling.
LDC-C100300-DHT
10.0 (32.8)
11.1…16.7
674…1012
(152…227)
34.3
1767 (397) 3.37…5.06
2097-V33PR5
2097-V32PR4
LDC-C100300-EHT 3.7…5.6 11.4
2097-V33PR3
2097-V32PR2
2097-V31PR2
LDC-C100400-EHT 7.4…11.1
899…1349
(202…303)
22.8 2356 (530) 4.49…6.74
2097-V33PR5
2097-V32PR4
Linear Motor
Speed, max
m/s (ft/s)
System Continuous
Stall Current
(1)
Amps 0-pk
(1) Values represent the range between no cooling (low value) and water cooling (high value).
System Continuous
Stall Force
(1)
N (lb)
System Peak
Stall Current
Amps 0-pk System Peak
Stall Force
N (lb) Linear Motor
Rated Output
(1)
kW
Kinetix 300 (2)
200V-class
Three-phase Drives
(2) Drives selected are for motors with no cooling.
LDC-C030100-DHT
10.0 (32.8)
4.1…6.1 74…111 (17…25) 12.1 188 (42) 0.37…0.55 2097-V33PR3
LDC-C030200-DHT 8.1…12.2
148…222 (33…50)
24.3
375 (84) 0.74…1.11
2097-V33PR5
LDC-C030200-EHT 4.1…6.1 12.1 2097-V33PR3
LDC-C050100-DHT
10.0 (32.8)
3.9…5.9 119…179 (27…40) 11.7 302 (68) 0.59…0.89 2097-V33PR3
LDC-C050200-DHT 7.9…11.8
240…359 (54…81)
23.3
600 (135) 1.20…1.79
2097-V33PR5
LDC-C050200-EHT 3.9…5.9 11.6 2097-V33PR3
LDC-C050300-DHT 11.8…17.7
363…544 (82…122)
35.9
941 (212) 1.81…2.72
2097-V33PR6
LDC-C050300-EHT 3.9…5.9 12.0 2097-V33PR3
LDC-C075200-DHT
10.0 (32.8)
7.7…11.5
348…523 (78…117)
22.9
882 (198) 1.74…2.61
2097-V33PR5
LDC-C075200-EHT 3.8…5.7 11.5 2097-V33PR3
LDC-C075300-DHT 11.5…17.2
523…784 (117…176)
35.6
1368 (308) 2.61…3.92
2097-V33PR6
LDC-C075300-EHT 3.8…5.7 11.9 2097-V33PR3
LDC-C075400-DHT 15.3…23.0
697…1045
(157…235)
47.4
1824 (410) 3.48…5.22
2097-V33PR6
LDC-C075400-EHT 7.7…11.5 23.7 2097-V33PR5
LDC-C100300-DHT
10.0 (32.8)
11.1…16.7
674…1012
(152…227)
34.3
1767 (397) 3.37…5.06
2097-V33PR5
LDC-C100300-EHT 3.7…5.6 11.4 2097-V33PR3
LDC-C100400-DHT 14.8…22.2
899…1349
(202…303)
45.7
2356 (530) 4.49…6.74
2097-V33PR6
LDC-C100400-EHT 7.4…11.1 22.8 2097-V33PR5
LDC-C150400-DHT 10.0 (32.8) 14.1…21.1
1281…1922
(288…432)
45.2 3498 (786) 6.40…9.61 2097-V33PR6
