Rockwell Automation Publication GMC-RM004C-EN-P - September 2013
Kinetix 300 and Kinetix 350 Drive Systems
Bulletin TLAR Performance Specifications with Kinetix 300/350 Drives
Performance Specifications (non-brake) with Kinetix 300/350 (200V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with actuator at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Performance Specifications (brake) with Kinetix 300/350 (200V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with actuator at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Electric Cylinder
Speed, max
mm/s (in/s)
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Motor Rated
Output
kW
Kinetix 300/350
200V-class Single-phase
or Three-phase Drives
TLAR-A1
xxxB
150
1.36
240 (53.9)
1.79
300 (67.4)
0.036
2097-V33PR1-
xx
2097-V32PR0-
xx
2097-V31PR0-
xx
TLAR-A1
xxxE
500
2.59
280 (62.9)
3.03
350 (78.7)
0.140
2097-V33PR1-
xx
2097-V32PR0-
xx
2097-V31PR0-
xx
TLAR-A2
xxxC
250
3.03
420 (94.4)
3.41
525 (118)
0.105
2097-V33PR1-
xx
2097-V32PR0-
xx
2097-V31PR0-
xx
TLAR-A2
xxxF
640
5.50
640 (144)
7.25
800 (180)
0.350
2097-V33PR1-
xx
2097-V32PR0-
xx
2097-V31PR0-
xx
TLAR-A3
xxxE
500
10.0
2000 (450)
12.9
2500 (562)
0.930
2097-V33PR5-
xx
2097-V32PR4-
xx
TLAR-A3
xxxH
1000
10.0
1300 (292)
17.2
1625 (365)
0.930
2097-V33PR5-
xx
2097-V32PR4-
xx
Electric Cylinder
Speed, max
mm/s (in/s)
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Motor Rated
Output
kW
Kinetix 300/350
200V-class Single-phase
or Three-phase Drives
TLAR-A1
xxxB
150
1.18
240 (53.9)
1.79
300 (67.4)
0.036
2097-V33PR1-
xx
2097-V32PR0-
xx
2097-V31PR0-
xx
TLAR-A1
xxxE
500
2.24
280 (62.9)
3.03
350 (78.7)
0.140
2097-V33PR1-
xx
2097-V32PR0-
xx
2097-V31PR0-
xx
TLAR-A2
xxxC
250
2.68
420 (94.4)
3.41
525 (118)
0.105
2097-V33PR1-
xx
2097-V32PR0-
xx
2097-V31PR0-
xx
TLAR-A2
xxxF
640
4.95
640 (144)
7.25
800 (180)
0.350
2097-V33PR1-
xx
2097-V32PR0-
xx
2097-V31PR0-
xx
TLAR-A3
xxxE
500
10.0
2000 (450)
12.9
2500 (562)
0.930
2097-V33PR5-
xx
2097-V32PR4-
xx
TLAR-A3
xxxH
1000
10.0
1300 (292)
17.2
1625 (365)
0.930
2097-V33PR5-
xx
2097-V32PR4-
xx
