Page 65

Rockwell Automation Publication GMC-RM004C-EN-P - September 2013
65
Kinetix 300 and Kinetix 350 Drive Systems
Kinetix 300/350 (200V-class) Drives with TL-Series Electric Cylinders
This section provides system combination information for the Kinetix 300/350 drives when matched with TL-Series
electric cylinders. Included are power/brake and feedback cable catalog numbers, system performance specifications, and
the optimum force/velocity curves.
Bulletin TLAR Cable Combinations
For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Motor/Actuator Cables Overview beginning on
.
Motor-end connector kits, and panel-mounted breakout components (drive end), are available for motor power/brake and feedback cables. Refer to Optional Drive Accessories on
.
Cable length
xx is in meters. Refer to the Kinetix Motion Accessories Technical Data, publica
, for standard cable lengths.
Electric Cylinder
Motor Power/Brake Cable
Motor Feedback Cable
(1)
(1) The TLY-A
xxxx-B motors with 17-bit high-resolution encoder feedback (mounted to the electric cylinder) require the 2090-CFBM6DF-CBAAxx flying-lead feedback cable and 2090-K2CK-D15M connector
kit with 2090-DA-BAT2 battery. Refer to Required Drive Accessories on
.
TLAR-A1
xxxB
TLAR-A1
xxxE
2090-CPWM6DF-16AA
xx (standard, non-flex)
(without brake)
2090-CPBM6DF-16AA
xx (standard, non-flex)
(with brake)
2090-CFBM6DF-CBAA
xx (standard, non-flex)
Absolute High-resolution Feedback
TLAR-A2
xxxC
TLAR-A2
xxxF
TLAR-A3
xxxE
TLAR-A3
xxxH
