Rockwell Automation 2097-V3xPRx-LM Kinetix 300 and Kinetix 350 Drive Systems Design Guide User Manual
Page 37

Rockwell Automation Publication GMC-RM004C-EN-P - September 2013
37
Kinetix 300 and Kinetix 350 Drive Systems
Kinetix 300 (200V-class) Drives/LDAT-Series Integrated Linear Thruster Curves (continued)
Velocity (m/s)
0
3
5
4
1
2
Force
(N)
Force
(lb)
400
350
300
250
200
150
100
50
0
89.9
78.7
67.4
56.2
45.0
33.7
22.5
11.2
0
2097-V31PR2, 2097-V32PR2, or 2097-V33PR3
and LDAT-S051050
-Dxx
Velocity (m/s)
0
3
5
4
1
2
Force
(N)
Force
(lb)
800
700
600
500
400
300
200
100
0
180
157
135
112
90.0
67.4
45.0
22.5
0
2097-V32PR4 or 2097-V33PR5
and LDAT-S052050
-Dxx
Velocity (m/s)
Force
(N)
Force
(lb)
0
1.5
2.5
2.0
0.5
1.0
3.0
800
700
600
500
400
300
200
100
0
180
157
135
112
90.0
67.4
45.0
22.5
0
2097-V31PR2, 2097-V32PR2, or 2097-V33PR3
and LDAT-S052050
-Exx
= Intermittent operating region
= Continuous operating region
= Intermittent operating region with 115V AC rms input voltage
Velocity (m/s)
Force
(N)
Force
(lb)
1200
1050
900
750
600
450
300
150
0
270
236
202
169
135
101
67.4
33.7
0
0
3
5
4
1
2
2097-V32PR4 or 2097-V33PR5
and LDAT-S053050
-Dxx
Velocity (m/s)
Force
(N)
Force
(lb)
0
1.5
2.5
2.0
0.5
1.0
3.0
1200
1050
900
750
600
450
300
150
0
270
236
202
169
135
101
67.4
33.7
0
2097-V33PR3 and LDAT-S053050
-Exx
