Kinetix 300 and Kinetix 350 Drive Systems
LDAT-Series Performance Specifications with Kinetix 300 (200V-class) Drives
Performance Specifications with Frame 30 Linear Thrusters
Linear Thruster
Cat. No.
Velocity, max
230V AC
m/s
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Rated Output
230V AC
kW
Kinetix 300 (200V-class) Drives
Single-phase Operation
Three-phase Operation
LDAT-S031010-D
xx
2.4
4.8
81 (18)
12.2
168 (38)
0.20
2097-V33PR3
2097-V32PR2
2097-V31PR2
2097-V33PR3
LDAT-S031020-D
xx
3.1
0.25
LDAT-S031030-D
xx
3.5
0.29
LDAT-S031040-D
xx
3.8
0.31
LDAT-S032010-D
xx
3.1
7.4
126 (28)
24.3
336 (76)
0.44
2097-V33PR5
2097-V32PR4
2097-V33PR5
LDAT-S032020-D
xx
4.1
0.52
LDAT-S032030-D
xx
4.7
0.59
LDAT-S032040-D
xx
5.0
0.63
LDAT-S032010-E
xx
3.1
3.7
12.2
0.40
2097-V33PR3
2097-V32PR2
2097-V31PR2
2097-V33PR3
LDAT-S032020-E
xx
4.1
0.47
LDAT-S032030-E
xx
4.7
0.52
LDAT-S032040-E
xx
5.0
0.55
LDAT-S033010-D
xx
3.5
11.1
190 (43)
36.5
504 (113)
0.67
2097-V33PR6
2097-V33PR6
LDAT-S033020-D
xx
4.7
0.88
LDAT-S033030-D
xx
5.0
0.95
LDAT-S033040-D
xx
LDAT-S033010-E
xx
3.5
3.7
12.2
0.55
2097-V33PR3
2097-V32PR2
2097-V31PR2
2097-V33PR3
LDAT-S033020-E
xx
4.4
0.65
LDAT-S033030-E
xx
LDAT-S033040-E
xx
Performance Specifications with Frame 50 Linear Thruster
Linear Thruster
Cat. No.
Velocity, max
230V AC
m/s
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Rated Output
230V AC
kW
Kinetix 300 (200V-class) Drives
Single-phase Operation
Three-phase Operation
LDAT-S051010-D
xx
2.8
3.1
119 (27)
11.4
363 (82)
0.31
2097-V33PR3
2097-V32PR2
2097-V31PR2
2097-V33PR3
LDAT-S051020-D
xx
3.7
0.38
LDAT-S051030-D
xx
4.1
0.42
LDAT-S051040-D
xx
4.4
0.44
LDAT-S051050-D
xx
4.7
0.46
LDAT-S052010-D
xx
3.7
6.2
251 (56)
22.7
727 (163)
0.79
2097-V33PR5
2097-V32PR4
2097-V33PR5
LDAT-S052020-D
xx
4.8
0.97
LDAT-S052030-D
xx
5.00
1.01
LDAT-S052040-D
xx
LDAT-S052050-D
xx
LDAT-S052010-E
xx
…
LDAT-S052050-E
xx
2.6
3.1
11.4
0.50
2097-V33PR3
2097-V32PR2
2097-V31PR2
2097-V33PR3
