Rockwell Automation 2097-V3xPRx-LM Kinetix 300 and Kinetix 350 Drive Systems Design Guide - Manual (Page 43)

Rockwell Automation Publication GMC-RM004C-EN-P - September 2013 43
Kinetix 300 and Kinetix 350 Drive Systems
Performance Specifications with Frame 50 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient, and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Performance Specifications with Frame 70 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient, and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Linear Thruster
Cat. No.
Velocity, max
460V AC
m/s System Continuous
Stall Current
Amps 0-pk System Continuous
Stall Force
N (lb) System Peak
Stall Current
Amps 0-pk System Peak
Stall Force
N (lb) Rated Output
460V AC
kW Kinetix 300
(400V-class) Drives
Three-phase Operation
LDAT-S051010-D xx 2.8
3.1 119 (27) 11.4 363 (82)
0.34
2097-V34PR5
LDAT-S051020-D xx 3.7 0.43
LDAT-S051030-D xx 4.1 0.49
LDAT-S051040-D xx 4.4 0.53
LDAT-S051050-D xx 4.7 0.55
LDAT-S052010-D xx 3.7
6.2
251 (56)
22.7
727 (163)
0.92
2097-V34PR6
LDAT-S052020-D xx 4.8 1.20
LDAT-S052030-D
xx
5.0 1.24 LDAT-S052040-D xx
LDAT-S052050-D xx
LDAT-S052010-E xx 3.7
3.1 11.4
0.80
2097-V34PR5
LDAT-S052020-E xx 4.6 0.98
LDAT-S052030-E xx
4.6 1.02 LDAT-S052040-E xx
LDAT-S052050-E xx
LDAT-S053010-E xx
…
LDAT-S053050-E
xx
3.5 3.1 378 (85) 11.4 1093 (246) 1.04 2097-V34PR5
LDAT-S054010-E xx 4.4
6.2 509 (114) 22.7 45.5
1.87
2097-V34PR6 LDAT-S054020-E xx
…
LDAT-S054050-E xx
5.0 1453 (327)
Linear Thruster
Cat. No.
Velocity, max
460V AC
m/s System Continuous
Stall Current
Amps 0-pk System Continuous
Stall Force
N (lb) System Peak
Stall Current
Amps 0-pk System Peak
Stall Force
N (lb) Rated Output
460V AC
kW Kinetix 300
(400V-class) Drives
Three-phase Operation
LDAT-S072010-D
xx
3.9
6.0
364 (82)
22.0
1055 (237)
1.37
2097-V34PR6
LDAT-S072020-D xx
5.0 1.64 LDAT-S072030-D xx
…
LDAT-S072070-D xx
LDAT-S072010-E xx
…
LDAT-S072070-E xx
3.5 3.0 11.0 1.03 2097-V34PR5
LDAT-S073010-E xx
…
LDAT-S073070-E xx
2.4 3.0 554 (125) 10.9 1576 (354) 1.01 2097-V34PR5
LDAT-S074010-E xx
…
LDAT-S074070-E xx
3.5 6.0 730 (164) 21.7 2088 (469) 2.08 2097-V34PR6
