Rockwell Automation Publication GMC-RM004C-EN-P - September 2013 25
Kinetix 300 and Kinetix 350 Drive Systems
Kinetix 300/350 (200V-class) Drives with TL-Series Low Inertia Motors
This section provides system combination information for the Kinetix 300/350 drives when matched with TL-Series™
(BulletinTLY) low-inertia motors. Compatible TL-Series motors are equipped with absolute high-resolution or
incremental encoder feedback. Included are motor power/brake and feedback cable catalog numbers, system performance
specifications, and the optimum torque/speed curves.
Bulletin TLY Motor Cable Combinations
TL-Series (Bulletin TLY) motors are characterized as having 1000 mm (39.4 in.) cable extensions with circular plastic connectors and TLY-A
xxx catalog numbers.
For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Motor/Actuator Cables Overview beginning on page 5 .
Motor-end connector kits, and panel-mounted breakout components (drive end), are available for motor power/brake and feedback cables. Refer to Optional Drive Accessories on page 4 .
Cable length xx is in meters. Refer to the Kinetix Motion Accessories Technical Data, publication GMC-TD004 , for standard cable lengths.
Bulletin TLY (non-brake) Motor Performance Specifications with Kinetix 300/350 (200V-class) Drives
Performance Specifications (non-brake) with Kinetix 300/350 (200V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient, and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Motor Cat. No. Motor Power/Brake Cable Motor Feedback Cable
(1)
(1) For TLY-A xxxx-H motors with incremental encoder feedback, use 2090-CFBM6DF-CBAAxx flying-lead cables and 2090-K2CK-D15M connector kit (battery not required) or use 2090-CFBM6DD-CCAAxx
(15-pin connector) cable on the drive end. Refer to Required Drive Accessories on page 3 for more information.
The TLY-A xxxx-B motors with 17-bit high resolution encoder feedback require the 2090-CFBM6DF-CBAAxx flying-lead feedback cable and 2090-K2CK-D15M connector kit with 2090-DA-BAT2 battery.
TLY-A110
x, TLY-A120x, TLY-A130x
2090-CPWM6DF-16AA
xx (standard, non-flex)
(without brake)
2090-CPBM6DF-16AA
xx (standard, non-flex)
(with brake)
2090-CFBM6DF-CBAA
xx or
2090-CFBM6DD-CCAA xx (standard, non-flex)
Absolute High-resolution or
Incremental Feedback
TLY-A220
x, TLY-A230x
TLY-A2530P, TLY-A2540P
TLY-A310M
Rotary Motor
Speed, max
m/s (ft/s)
System Continuous
Stall Current
A 0-pk System Continuous
Stall Torque
N•m (lb•in) System Peak
Stall Current
A 0-pk System Peak
Stall Torque
N•m (lb•in) Motor Rated
Output
kW Kinetix 300/350
200V-class Single-phase
or Three-phase Drives
TLY-A110 x
6000 (1)
(1) Applies to TLY-A xxxT-H motors with incremental feedback. The TLY-AxxxT-B motors with absolute high-resolution encoders are rated for 5000 rpm.
0.55 0.096 (0.85) 1.50 0.20 (1.75) 0.041
2097-V33PR1- xx
2097-V32PR0- xx
2097-V31PR0-
xx
TLY-A120 x 1.03 0.181 (1.60) 2.50 0.36 (3.20) 0.086
2097-V33PR1- xx
2097-V32PR0- xx
2097-V31PR0- xx
TLY-A130 x 1.85 0.325 (2.88) 4.90 0.76 (6.70) 0.14
2097-V33PR1- xx
2097-V32PR0- xx
2097-V31PR0- xx
TLY-A220
x
3.50 0.836 (7.40) 7.90 1.48 (13.1) 0.35
2097-V33PR1-
xx
2097-V32PR0- xx
2097-V31PR0- xx
TLY-A230 x 5.50 1.30 (11.5) 15.5 3.05 (27.0) 0.44
2097-V33PR3- xx
2097-V32PR2- xx
2097-V31PR2- xx
