54 Rockwell Automation Publication IASIMP-QS025B-EN-P - December 2012
Chapter 4 Configure the DeviceNet Network
• The tasks described in Chapter 2, Prepare the Computer and Load Controller Firmware on
page 31 , including the following:
– Install the Studio 5000 environment and RSLinx Classic software.
Logix Designer application is installed when you install the Studio 5000 environment.
– Load firmware on the controller.
• Verify that power is applied to all devices.
What You Need
Table 8 lists the components you use in this chapter.
Table 8 - What You Need to Configure the DeviceNet Network
Component Description
RSNetWorx for DeviceNet software Configuration software that creates a scanlist of devices that exchange information with the
controller over a DeviceNet network.
DeviceNet power components Components necessary to power the DeviceNet network.
This example uses the 1606-XLDNET8 and a KwikLink power tap module.
