30

Rockwell Automation Publication IASIMP-QS025B-EN-P - December 2012

Chapter 1

Prepare the CompactLogix 5370 L2 Controller Hardware

Wire the DeviceNet Network Power Supply

1. Use the information in the following table to connect incoming power to the network

power supply.

2. Place the switch in the position that matches your supply voltage.

3. Use the information in the followingtable to connect the DeviceNet power tap to the

power supply.

4. Connect the DeviceNet power tap to the DeviceNet network.

5. Power the 1606- XLDNET4 standard switched-mode power supply connected to the

CompactLogix 5370 L2 controller, as described in

Connect Power to the Controller on

page 25

.

WARNING: Verify that all incoming power is turned off before wiring power.

Connect

To

V AC COM

N (neutral)

120/240V AC

L (line)

Ground

Connect

To

Red

+

White

N/A

Shield

N/A

Blue

N/A

Black

ATTENTION: If you have unused DeviceNet wires, make sure they do not come into contact with the other wires.
