Where to start – Rockwell Automation 1769-L24ER-QB1B_L24ER-QBFC1B_L27ERM-QBFC1B CompactLogix 5370 L2 Controllers Quick Start User Manual
Page 3
Rockwell Automation Publication IASIMP-QS025B-EN-P - December 2012
3
Where to Start
Follow the path that matches your hardware and network configuration.
+24VDC COM
FG
00:00:BC:2E:69:F6
L27ERM
QBFC1B
+24VDC COM
FG
00:00:BC:2E:69:F6
L27ERM
QBFC1B
Prepare the CompactLogix 5370 L2
Required
Required
Optional
Required
Optional
POINT I/O
™
Modules
Kinetix
®
350
Drive
PowerFlex
®
40
Drive
PowerFlex 70
Drive
PanelView
™
Plus Terminal
