Rockwell Automation Publication IASIMP-QS025B-EN-P - December 2012

17

Chapter

1

Prepare the CompactLogix 5370 L2 Controller Hardware

This chapter describes the hardware required to install your CompactLogix 5370 L2 system.

Before You Begin

Determine which networks your control system uses. You can use CompactLogix 5370 L2
controllers on an EtherNet/IP network and on a DeviceNet network.

What You Need

Table 4

lists the hardware components used in this chapter. The parts listed in this table are done

so with the assumption that you will install an EtherNet/IP and DeviceNet network.

Table 4 - Parts Used with This Quick Start

Quantity

Cat. No.

Description

1 or more

N/A

DIN rail (steel, not aluminum)

1

1769-L27ERM-QBFC1B

CompactLogix 5370 L2 controller

1

1606-XLDNET8

DeviceNet power supply

1

1769-ECR

Compact I/O end cap/terminator

2 or more

1585J-M8PBJM-2

RJ45-to-RJ45 patchcord Ethernet cables

1

-

USB cable with Type B receptacle

1

1783-EMS08T

Stratix 6000 Ethernet managed switch

1

1606-XLDNET4

Standard switched-mode power supply

1

1769-OB16

Compact 16-point 24V DC sourcing output module

1

1769-SDN

Compact I/O DeviceNet scanner

1

1485C-P1E75

KwikLink flat cable, 75 m (246 ft)

2

1485A-T1E4

KwikLink terminator/resistor

2 or more

1485P-P1E4-R5

KwikLink sealed micro connector
