Choose to integrate optional devices, Desc, Choose to – Rockwell Automation 1769-L24ER-QB1B_L24ER-QBFC1B_L27ERM-QBFC1B CompactLogix 5370 L2 Controllers Quick Start User Manual
Page 11
Rockwell Automation Publication IASIMP-QS025B-EN-P - December 2012
11
Preface
This graphic shows a CompactLogix 5370 L2 control system that matches the system you will
install after completing steps.
Choose to Integrate Optional Devices
You can integrate multiple optional devices into a CompactLogix 5370 L2 control system. You
can use these devices on DeviceNet or EtherNet/IP networks.
This table describes optional devices you might use in a CompactLogix 5370 L2 control
controller system and what resources to use for each.
Table 1 - Devices in Logix5000 Control System
Device Type
Product Line
(1)
Additional Resource with More Information
Distributed I/O
POINT I/O
Logix5000 Control Systems: Connect POINT I/O Modules over a DeviceNet Network
Quick Start, publication
Logix5000 Control Systems: Connect POINT I/O Modules over an EtherNet/IP Network
Quick Start, publication
+24VDC COM
FG
00:00:BC:2E:69:F6
L27ERM
QBFC1B
