Overview of the DL40 Plus 1–16
Publication 2706-6.1
The following keyboards are compatible with the DL40 Plus.
Catalog No. Description
6189-KBD1 Industrial Keyboard
6189-KBE1 Industrial Spill-Proof Keyboard
6186-KBM1 Industrial Panel Mount Membrane Keyboard
Note: When used with the DL40 Plus, the Num Lock and Caps Lock
indicators will not illuminate.
Options and accessories for the DL40 Plus are listed below.
Item Description Catalog No.
Offline
Programming
Software
DOS based software to configure the DL40 Plus (Four 3 1/2
inch diskettes). 2706-LSW
Communication
Cables
For connecting the DL40 Plus to a range of PCs and
converters. The 2706–NC13 cable is recommended for
programming from a personal computer.
See Appendix C for detailed information on cables.
2706-NC12
2706-NC13
2706-NC14
2706-NC15
120 Volt
Parallel Input
Converter
Converter to connect 120 VAC input voltages to parallel input
port (2 required for each DL40 Plus) 2706-NG2
NEMA
Enclosure
NEMA Type 12/13 enclosure complete with mounting holes
and cutout for one DL40 Plus display. Access door is
gasketed.
Enclosure for two-line DL40 Plus
Enclosure for four-line DL40 Plus
2706-NE1
2706-NE2
Keyboard Front
Panel Access
Kit
Panel mount 8-pin DIN keyboard connecter, NEMA 4 panel
access cover, keyboard extension cable 2706-NKAK1
RS-232 Front
Panel Access
Kit
Panel mount 9-pin D shell connector, NEMA 4 panel access
cover, DL40 Plus RS-232 extension cable 2706-NDAK2
The following repair parts are available for the DL40 Plus.
•
2–line front panel assembly, Allen–Bradley part number
W7715680001.
•
4–line front panel assembly, Allen–Bradley part number
W7715680002.
•
Battery replacement for the real-time clock, Allen-Bradley
Catalog No. 2711-NB4.
These repair parts are available to replace the front panel faceplate
and graphic overlay assembly or real-time clock battery.
Note: A qualified service technician is required to install these
repair parts.
Compatible Keyboards
Options and Accessories
Repair Parts
