Overview of the DL40 Plus 1–15
Publication 2706-6.1
PassThrough Support over an Ethernet Link
The following table lists the Allen-Bradley PLCs that support
PassThrough file transfers with the DL40 Plus message display over
an Ethernet link as of this printing.
PLC Types Series Revision
PLC 5/40E
A
B E or later
PLC 5/60E
A
B B or later
PLC 5/80E All All
PLC 5/250 All All
Use one of the Allen-Bradley Ethernet computer interface boards (or
its equivalent) for PassThrough file transfers.
•
Catalog Number 6628-A5: Ethernet adapter module for IBM PC
compatible computers
•
Catalog Number 6628-A7: Ethernet adapter module for IBM
MicroChannel bus compatible computers
DL40 Plus displays are available with 128K bytes of memory in
either 2- or 4-line versions with two communication options.
Display Type:
2 – Two–line
4 – Four–line Communication Options:
R – RIO
P – Parallel Port
S – Slave
2706–LV2R
The table below shows the standard catalog numbers for the DL40
Plus and how they equate to previous versions of the DL40 displays.
DL40 Plus
Catalog Number
Description
Equivalent Catalog Numbers for
Previous Versions of the DL40
2706–LV2P Two–line display, AC supply
with parallel port
2706–E23J16, 2706–E23C16
2706–E23J32, 2706–E23C32
2706–LV4P Four–line display, AC supply
with parallel port
2706–E43J32, 2706–E43C32
2706–E43J64, 2706–E43C64
2706–E43J128, 2706–E43C128
2706–LV2R Two–line display, AC supply
with remote I/O
2706–E23J16B1, E23C16B1
2706–E23J32B1, 2706–E23C32B1
2706–LV4R Four–line display, AC supply
with remote I/O
2706–E43J32B1, 2706–E43C32B1
2706–E43J64B1, 2706–E43C64B1
2706–E43J128B1, 2706–E43C128B1
Available Catalog Numbers
