DIP Switch Settings
10–4
Publication 2706-6.1
Setting Switch Bank #2
Use the following tables to identify switch functions and settings for
Switch Bank #2 on Remote I/O version.
Switch 1 and 2 Settings
Baud
Switch Settings
Rate
1
2
57.6K
ON
ON
115.2K
OFF
ON
230.4K
ON or OFF
OFF
Switch 3 - 10 Settings
Switch Settings
Switch
Description
OFF
ON
3
Fast Reset
Disabled
Enabled
4
Block Transfer
Disabled
Enabled
5
Last Chassis
Last
Not Last
6
Keyboard Type
IBM–AT
IBM–XT
7
Handshake
Disabled
Enabled
8
Last State
Disabled
Enabled
9
Select Button
Disabled
Enabled
10
No PLC Communications Enabled
Disabled
Fast Reset Sequence (Switch #3)
If the Fast Reset DIP switch is set to ON, the DL40 Plus displays
only the Firmware Version, Screen Test, and the Selected Run Mode.
All other prompts are skipped (but the tests will still be run). If any
of the tests fail, then that error message will still appear. If the Fast
Reset DIP switch is set to OFF, the DL40 Plus displays the Firmware
Version, Memory Verification, External Module Verification, Screen
Test, RS-232 Port Settings, RS-485 Port Settings, Remote I/O
Settings, and the Selected Run Mode.
Block Transfer Enabled (Switch #4)
If the Block Transfer Enabled DIP switch is set to ON, then block
transfer files are used for communication with the PLC. If the Block
Transfer Enabled DIP switch is set to OFF, then Discrete I/O is used
to communicate with the PLC.
Last Chassis (Switch #5)
The Last Chassis setting tells the PLC if the DL40 Plus is the last
device of that logical rack, not necessarily the last rack of the remote
I/O link.
