Overview of the DL40 Plus 1–2
Publication 2706-6.1
RS-485/RS-232 Communications
Both the Remote I/O and Parallel Port versions have RS-485 and
RS-232 ports. You can configure these ports for Programmer, DL
Slave or Open Protocol communications (see table below). Port
settings are modified through the Ports menu in the Offline
Programming software or the Onboard Editor. You select a
communication option under the Port Use submenu.
The RS-232 port always communicates with the Offline
Programming Software regardless of the configured mode. Open
Protocol or DL Slave operation can occur on either the RS-232 or
RS-485 port.
If the RS-485 port is configured for Open protocol, you cannot
configure the RS-232 port for the same protocol. Instead, an
information message reports an invalid port configuration.
Con urat ons escr pt on Plus Port
Communication/Printing Options
Configurations Description DL40 Plus Port
Programmer Open Protocol Slave Printing
Offline Programming
RS–485 √
1
Offline Programming
and Serial Printing RS–232
√ √
RS-232 Offline Programming
RS–485
√
2
RS-232 Offline Programming
and RS-485 Message Triggering RS–232
√ √
3
RS-232 Offline Programming
RS–485
√
3
RS-232 Offline Programming
RS-485 Slave Communications RS–232
√ √
RS-485 Offline Programming
RS–485
√
4
RS-485 Offline Programming
RS-232 Message Triggering RS–232
√
RS-485 Slave Communications
RS–485
√
5
RS-485 Slave Communications
RS-232 Message Triggering RS–232
√
RS-485 Offline Programming
RS–485
√
6
RS-485 Offline Programming
RS-232 Slave Communications RS–232
√
RS-485 Message Triggering
RS–485
√
7
RS-485 Message Triggering
RS-232 Slave Communications RS–232
√
Note: Open protocol is a serial ASCII based format for triggering
messages stored in the DL40 Plus displays. Open protocol supports
message triggers with or without variable data over the RS-232 or
RS-485 serial ports.
