Process Configuration and Operation Software for Windows t 7
Publication 6723Ć10.1 Ć August 1996
If you are using the 1784-PCMK card:
With the PCMK card, you must also set the PCMK enabler.
From the INTERCHANGE Device Configuration screen, click on
the Advanced button. The INTERCHANGE Advanced Device
Configuration dialog box appears.
In the PCMK Enabler Selection section, select one of the following:
•
If you are using the Windows 95 Plug-n-Play driver (RSIPCMK),
or if you are using Cardware, Cardsoft, etc. and PCMKINIT,
choose Specific and click on OK.
•
If you are using Cardware and PCENABLE, choose Generic and
click on OK.
The INTERCHANGE Device Configuration screen returns.
If you choose Specific, when you click on the Add Device button,
the 1784-PCMK on DH+ dialog box appears as follows. You must
enter the Socket # on this screen.
Important: Rockwell Software currently refers to sockets by a
zero-based socket number, while Windows 95 begins
numbering at 1. Therefore, specifying socket number 0
in Interchange actually refers to the socket that
Windows 95 recognizes as socket 1.
