Process Configuration and Operation Software for Windows
t
10
Publication 6723Ć10.1 Ć August 1996
Installing the Software
Follow this flowchart to install PCO software:
START
Type
a:\setup
.
If you elected to install FIX
faceplates, PCO prompts
you to enter the directory
where FIX is installed.
(e.g. C:\WDMACS)
DONE
For Windows 3.1: From the
Program Manager File
pullĆdown menu, select Run.
Insert disk 1 of the
PCO 6723ĆPCO
software into drive a.
Click on the checkboxes to
select the PCO components
you wish to install (all are
optional).
Click on Continue.
Do you wish to
install PCO in the
default directory?
NO
YES
Click on the Change
Directory button and enter
the directory where you wish
to install PCO.
If you elected to install
Factory Link faceplates, PCO
prompts you to enter the
directory where FactoryĆLink
is installed.
(e.g. C:\FLWIN)
For Windows 95: Click
on the Start button and
select Run.
If you elected to install
RSView faceplates, PCO
prompts you to enter the
directory where RSView is
installed.
(e.g. C:\RSI)
Note: To complete the steps
outlined in this document, you must
install the PCO Excel Configurator
and the Library Manager.
