Rockwell Automation 6723-PCO DATA PROCESS CONFIG OPERATIO User Manual
Page 35
Process Configuration and Operation Software for Windows
t
33
Publication 6723Ć10.1 Ć August 1996
You can use the PCO faceplates to monitor configured I/O interface,
process control, and discrete control functions.
For additional information about monitoring and controlling your
process functions through the faceplates, refer to Chapter 5 and
Appendices C, D, and E of your Process Configuration and
Operation Software User Manual (publication 6723-6.5.1).
In this Quick Start, you have completed the steps necessary to:
•
define your process and control requirements
•
develop your PLC code for use with PCO software
•
create JSR instructions and Data Table files
•
configure your process functions
•
download the appropriate information into your PLC processor
Use the techniques that you learned here to configure your own
applications for use with PCO software.
Using the Faceplates to
Monitor and Control Your
Process Functions
Summary
