1–7 Introducing PanelBuilder 1400e
Publication 2711E-818 – January 1998
In the illustration below, the PanelView terminals are connected by a
ControlNet network.
24717
Development Computer
Machine or
Process
PanelView
Programmable
Controller
ControlNet PanelView
1000e/1400e Terminal
(Touch Screen)
ControlNet
Machine or
Process
Programmable
Controller
Allen–Bradley PanelView 1000e
PanelView
ControlNet PanelView
1000e/1400e Terminal
(Touch Screen)
Allen–Bradley PanelView 1000e
The application is created in PanelBuilder on the
personal computer, and downloaded to the
PanelView operator terminal.
The PanelView terminal queries
the PLC for process or machine
status information.
Operator input to the terminal is
sent to the PLC. The PLC uses this
information to control the machine
or process.
Serial Connection
Tip: For connection diagrams, see Figures 2.1 through 2.7 in
Chapter 2, “Working with the PanelView 1200/1400e Transfer
Utility,” in the PanelView 1200/1400e Transfer Utility User Manual.
"
