Rockwell Automation 2711E-ND1 PanelBuilder 1400E Configurator Software Getting Started User Manual
Page 15
1–3
Introducing PanelBuilder 1400e
Publication 2711E-818 – January 1998
The application screens created in PanelBuilder appear on the
PanelView terminal, replacing traditional hard-wired control panels.
The screens provide the physical interface between the PLC and the
human operator.
Application screens contain objects that function like control panel
components. By using these objects to enter data or carry out
commands, the operator can monitor and control the process.
Touch Screen Terminals
Keypad Terminals
PanelView 1000e
Terminals
PanelView 1200e
Terminals
PanelView 1400e
Terminals
