Publication 1769-UM001B-EN-P - October 2002
Explicit Messaging Application Examples B-25
Should a configuration error occur, you will receive DeviceNet Error
Codes. The error code is a two-byte field, where the low byte is the
General Error Code and the high bit is the Additional Error Code.
The following is a list of possible DeviceNet Error Codes:
Error Code
(Hexadecimal) Description of Error
00 Success Service was successfully performed by the object specified.
01 Reserved by DeviceNet for future extensions
02 Resource unavailable - Resources needed for the object to perform the
requested service were unavailable.
03 Reserved by DeviceNet for future extensions
04 Path segment error - The path segment identifier or the segment
syntax was not understood by the processing node. Path processing
shall stop when a path segment error is encountered.
05 Path destination unknown - The path is referencing an object class,
instance, or structure element that is not known or is not contained in
the processing node. Path processing shall stop when a path
destination unknown error is encountered.
06 Reserved by DeviceNet for future extensions
07 Connection lost - The messaging connection was lost.
08 Service not supported - The requested service was not implemented or
was not defined for the Object Class/Instance.
09 Invalid attribute value, invalid attribute data detected
0A Attribute list error - An attribute in the Get_Attribute_List or
Set_Attribute_List response has a non-zero status.
0B Already in requested mode/state - The object is already in the
mode/state being requested by the service.
0C Object state conflict - The object cannot perform the requested service
in its current mode/state.
0D Object already exists - The requested instance of the object to be
created already exists.
0E Attribute not settable - A request to modify a non-modifiable attribute
was received.
0F Privilege violation - A permission/privilege check failed.
10 Device state conflict - The device’s current mode/state prohibits the
execution of the requested service.
11 Reply data too large - The data to be transmitted in the response buffer
is larger than the allocated response buffer.
12 Reserved by DeviceNet for future extensions
13 Not enough data - The service did not supply enough data to perform
the specified operation.
14 Attribute not supported - The attribute specified in the request is not
supported.
15 Too much data - The service supplied more data than was expected.
