6-10 Application Examples

Input Image

I:3.0

1747-SDN Status

I:3.1

1769-ADN Status Word 0

I:3.2

1769-ADN Status Word 1

I:3.3

Slot 1 Input Card, Input Data (1769-IA16)

I:3.4

Slot 2 Output Card, Output Echo Data (1769-OW8)

I:3.5

Slot 3 Input Card, Input Data (1769-IA16)

I:3.6

Slot 4 Output Card, Output Echo Data (1769-OW8)

I:3.7

Slot 5 Combo Card, Input Data (1769-IQ6XOW4)

I:3.8

Slot 5 Combo Card, Output Echo Data (1769-IQ6XOW4)

I:3.9

Slot 6 Combo Card, Input Data (1769-IQ6XOW4)

I:3.10

Slot 6 Combo Card, Output Echo Data (1769-IQ6XOW4)

I:3.11

Slot 7 Input Card, Input Data (1769-IQ16)

I:3.12

Slot 8 Output Card, Output Echo Data (1769-OV16)

I:3.13

Slot 9 Analog Input Card, Input Data 0 (1769-IF4)

I:3.14

Slot 9 Analog Input Card, Input Data 1 (1769-IF4)

I:3.15

Slot 9 Analog Input Card, Input Data 2 (1769-IF4)

I:3.16

Slot 9 Analog Input Card, Input Data 3 (1769-IF4)

I:3.17

Slot 9 Analog Input Card, Status Data (1769-IF4)

I:3.18

Slot 9 Analog Input Card, Status Data (1769-IF4)

I:3.19

Slot 10 Analog Output Card, Status Data (1769-OF2)

I:3.20

Slot 10 Analog Output Card, Status Data (1769-OF2)

I:3.21

Slot 10 Analog Output Card, Output Echo 0 (1769-OF2)

I:3.22

Slot 10 Analog Output Card, Output Echo 1 (1796-OF2)

I:3.23

Slot 11 Input Card, Input Data (1769-IQ16)

I:3.24

Slot 12 Output Card, Output Echo Data (1769-OB16)

I:3.25

Slot 13 Input Card, Input Data (1769-IQ16)

I:3.26

Slot 14 Output Card, Output Echo Data (1769-OV16)
