Series a adapters input/output specifications – Rockwell Automation 1769-ADN Compact I/O 1769-ADN DeviceNet Adapter User Manual
Page 154
Publication 1769-UM001B-EN-P - October 2002
A-2 Specifications
Series A Adapters Input/Output Specifications
Specification
Value
Bus Current Draw (Maximum) 450mA at 5V dc (2.25W)
Heat Dissipation
4.7W maximum
I/O Capacity
30 modules
Communication Rate
125k bit/s
250k bit/s
500k bit/s
Indicators
Module status
- red/grn
Network status - red/grn
I/O status
- red/grn
Diagnostic status- red/grn
DeviceNet Power
Requirements
24V dc (+4%) @ 90mA maximum, N.E.C. Class 2
DeviceNet Cable
Allen-Bradley part no. 1485C-P1-Cxxx. Refer to
publication DN-2.5 for more information.
Power Supply Distance Rating
4
(The adapter may not be more than 4 modules away
from the power supply.)
Output to Backplane Isolation
Verified by one of the following qualification tests:
710V dc, 1 minute
Vendor I.D. Code
1
Product Type Code
12
Product Code
69
