Publication 1746-UM026A-EN-P - September 2003

4-8 Configuring the Module

Data Format (configuration bits 4 to 6)

Use this bit field to select one of the following formats:

1746-NO4 compatible format (the format used by the 1746-NO4)

engineering units (mV or nA)

scaled for PID (works with the SLC PID instruction)

proportional counts (two’s complement binary)

user-defined scale

These data formats and ranges are defined in the following table:

Table 4.3 1746-NO8 Data Format Definitions

Data Format

Selected
Output
Range

Data Value (counts)

Corresponding Signal

Min.

Max.

Min.

Max.

1746-NO4
Compatible

(1)

(1) Provides direct compatibility with the 1746-NO4 module.

±10V dc
0 to 10V dc
0 to 5V dc
1 to 5V dc
0 to 20 mA
0 to 21 mA
4 to 20 mA

-32768
0
0
+3277
0
0
+6242

+32764
+32764
+16384
+16384
+31208
+32764
+31208

-10V dc
0V dc
0V dc
+1V dc
0 mA
0 mA
4 mA

+10V dc
+10V dc
+5V dc
+5V dc
20 mA
21 mA
20 mA

Engineering
Units

±10V dc
0 to 10V dc
0 to 5V dc
1 to 5V dc
0 to 20 mA
0 to 21 mA
4 to 20 mA

-10250
-500
-500
+500
0
0
+3500

+10250
+10250
+5500
+5500
+20500
+21500
+20500

-10.25V dc
-0.50V dc
-0.50V dc
+0.50V dc
0.0 mA
0.0 mA
3.5 mA

+10.25V dc
+10.25V dc
+5.50V dc
+5.50V dc
20.5 mA
21.5 mA
20.5 mA

Scaled for PID

±10V dc
0 to 10V dc
0 to 5V dc
1 to 5V dc
0 to 20 mA
0 to 21 mA
4 to 20 mA

0
0
0
0
0
0
0

+16383
+16383
+16383
+16383
+16383
+16383
+16383

-10V dc
0V dc
0V dc
+1V dc
0 mA
0 mA
4 mA

+10V dc
+10V dc
+5V dc
+5V dc
20 mA
21 mA
20 mA

Proportional
Counts

±10V dc
0 to 10V dc
0 to 5V dc
1 to 5V dc
0 to 20 mA
0 to 21 mA
4 to 20 mA

-32768
-32768
-32768
-32768
-32768
-32768
-32768

+32767
+32767
+32767
+32767
+32767
+32767
+32767

-10.25V dc
-0.50V dc
-0.50V dc
+0.50V dc
0.0 mA
0.0 mA
3.5 mA

+10.25V dc
+10.25V dc
+5.50V dc
+5.50V dc
20.5 mA
21.5 mA
20.5 mA

User-Defined
Scale

(2)

(2) For the user-defined scale, the data in output data parameter words 1 and 2 determine the count limits. See

page 4-12 for information on the User-Defined Scale data format.

±10V dc
0 to 10V dc
0 to 5V dc
1 to 5V dc
0 to 20 mA
0 to 21 mA
4 to 20 mA

-10.25V dc
-0.50V dc
-0.50V dc
+0.50V dc
0.0 mA
0.0 mA
3.5 mA

+10.25V dc
+10.25V dc
+5.50V dc
+5.50V dc
20.5 mA
21.5 mA
20.5 mA
