Publication 1746-UM026A-EN-P - September 2003

Configuring the Module 4-5

d. The “Options” pull-down allows selection of the data format

(bits 4 to 6 of the channel configuration word):

Options:
1746-NO4 Data Format
Engineering Units
Scaled for PID
Proportional Counts
User-defined

e. “Latch Alarms” and “Reset Latched Alarms” check boxes allow

channel configuration word bits 14 and 15 to be configured.

f. The “Fault Options” pull-down allows channel configuration

fault options to be selected (bits 12 and 13 of the channel
configuration word).

Fault Options:
Reset Output
Hold Output
Preset Output

Refer to the remaining sections of this chapter for a full description of
the available configuration selections.
