Configurable Flowmeter Module Features and Operational Modes 59
How To Enable Output Behavior Configuration
To enable output behavior configuration for a 1756-CFM module with
firmware revision 2.4, select one of these options.
 If you are using RSLogix 5000 software version 16 or earlier, see
Appendix E on page 147 .
 If you are using RSLogix 5000 software version 17 or later, add a new
module to your I/O Configuration folder and complete the following
steps.
1. On the Select Module screen, select the 1756-CFM module and click
OK.
The Select Major Revision window opens.
2. Verify that Major Revision 2 is chosen and click OK.
The New Module dialog box opens with Major Revision 2 chosen.
Output Behavior configuration is enabled.
