127 Rockwell Automation Publication 1756-UM010B-EN-P - December 2011
Software Configuration Tags 127
C.Operations[1].kFactStruct.FreqAtKFactor[8] Float REAL Freq[8] for KFactor [8]
C.Operations[1].kFactStruct.FreqAtKFactor[9] Float REAL Freq[9] for KFactor [9]
C.Operations[1].kFactStruct.FreqAtKFactor[10] Float REAL Freq[10] for KFactor [10]
C.Operations[1].kFactStruct.FreqAtKFactor[11] Float REAL Freq[11] for KFactor [11]
C.Operations[1].kFactStruct.FreqAtKFactor[12] Float REAL Freq[12] for KFactor [12]
C.OutputSetup[0].FaultMode Decimal SINT Sets the state of output 0 when communications are lost
with the owner-controller in Fault Mode
0 = Continue operation
1 = Reset Output 0 to OFF when in Fault Mode
2 = Set Output 0 to ON when in Fault Mode
C.OutputSetup[0].ProgMode Decimal SINT Sets the state of output 0 when communications are lost
with the owner-controller in Program Mode
0 = Continue operation
1 = Reset Output 0 to OFF when in Program Mode
2 = Set Output 0 to ON when in Program Mode
C.OutputSetup[0].DynamicError Decimal SINT Sets the state of output 0 when a dynamic error occurs
0 = Continue operation
1 = Reset Output 0 to OFF on Error
2 = Set Output 0 to ON on Error
C.OutputSetup[0].TriggerOn Decimal SINT Sets when output 0 energizes
0 = No Action
1 = Frequency
2 = Acceleration
3 = Full Flow State
4 = Trickle Flow State
5 = Prover Run State
6 = Prover Range State
C.OutputSetup[0].TieToCounter Ties a channel to output 0
0 = No connection
1 = Connect Channel0 to Output0
2 = Connect Channel1 to Ouput0
C.OutputSetup[1].FaultMode Decimal SINT Sets the state of output 1 when communications are lost
with the owner-controller in Fault Mode
0 = Continue operation
1 = Reset Output 0 to OFF when in Fault Mode
2 = Set Output 0 to ON when in Fault Mode
C.OutputSetup[1].ProgMode Decimal SINT Sets the state of output 1 when communications are lost
with the owner-controller in Program Mode
0 = Continue operation
1 = Reset Output 0 to OFF when in Program Mode
2 = Set Output 0 to ON when in Program Mode
Table 13 - Configurable Flowmeter Module Configuration Tags
Name Style Data type Definition
