Configuring the Configurable Flowmeter Module 103
C.Operations[0].MeterFactor Float REAL Calibration Adjust for metering reading
applied after K-factor correction. Typically,
this factor is between 0.8 and 1.2 but the
module restricts the value>0.
1.0
C.Operations[0].FilterResolution Float REAL Sets resolution of the Speed calculation
based on the raw counts
0 = default of 0.00001
0.00001 = resolution of + 1 count of 100,000
raw counts.
0.166
C.Operations[0].SampleTime Float REAL Sets time for a sample to be taken.
(2.0 second maximum sample time for high
resolution frequency mode and 5.0 seconds
for totalizer mode)
0.5
C.Operations[0].kFactStruct.kFactorForChan[0] Float REAL K-factor 0 for Channel 0 when frequency is <
FreqAtKFactor[1]
600.0
C.Operations[0].kFactStruct.kFactorForChan[1] Float REAL This tag is an ordered pair with tag
C.Operations[0].kFactStruct.FreqAtKFactor
[1]
600.0
C.Operations[0].kFactStruct.kFactorForChan[2] Float REAL This tag is an ordered pair with tag
C.Operations[0].kFactStruct.FreqAtKFactor
[2]
550.0
C.Operations[0].kFactStruct.kFactorForChan[3] Float REAL This tag is an ordered pair with tag
C.Operations[0].kFactStruct.FreqAtKFactor
[3]
0.0
C.Operations[0].kFactStruct.kFactorForChan[4] Float REAL This tag is an ordered pair with tag
C.Operations[0].kFactStruct.FreqAtKFactor
[4]
0.0
C.Operations[0].kFactStruct.kFactorForChan[5] Float REAL This tag is an ordered pair with tag
C.Operations[0].kFactStruct.FreqAtKFactor
[5]
0.0
C.Operations[0].kFactStruct.kFactorForChan[6] Float REAL This tag is an ordered pair with tag
C.Operations[0].kFactStruct.FreqAtKFactor
[6]
0.0
C.Operations[0].kFactStruct.kFactorForChan[7] Float REAL This tag is an ordered pair with tag
C.Operations[0].kFactStruct.FreqAtKFactor
[7]
0.0
C.Operations[0].kFactStruct.kFactorForChan[8] Float REAL This tag is an ordered pair with tag
C.Operations[0].kFactStruct.FreqAtKFactor
[8]
0.0
C.Operations[0].kFactStruct.kFactorForChan[9] Float REAL This tag is an ordered pair with tag
C.Operations[0].kFactStruct.FreqAtKFactor
[9]
0.0
C.Operations[0].kFactStruct.kFactorForChan[10] Float REAL This tag is an ordered pair with tag
C.Operations[0].kFactStruct.FreqAtKFactor
[10]
0.0
Table 8 - Tag Changes Required for Totalizer Mode Using Prover Function
Name Style Data type Definition Enter this
Value
