Appendix
E
Configure Output Behavior with
RSLogix 5000 Version 16 and Earlier
If you have a 1756-CFM module with firmware revision 2.4 and are using
RSLogix 5000 software, version 16 or earlier, use this procedure to enable and
configure the output behavior. If you do not want to use the output behavior
features available in firmware revision 2.4, you do not need to complete this
procedure. For an explanation of the output behavior features, see
Configurable Output Behaviors on page 58
To complete the configuration, you must download and open the
CFM_GenericProfileExample.ACD file from one of the following locations:
As packaged with the1756-CFM firmware revision 2.4 firmware kit
provided at
In the RSLogix 5000 software version 16 quick start page:
– To open the file, click the Controller Projects tab. Then choose Open
Sample Project > V16 > Rockwell Automation >
CFM_GenericProfileExample.ACD.
Once you have downloaded and opened the
CFM_GenericProfileExmple.ACD file, complete the configuration procedure
that matches your application.
IMPORTANT
Use these configuration procedures only if you are
configuring your 1756-CFM module by using RSLogix 5000
software version 16 or earlier.
If you are using the module in
Go to
A new application
Configure the 1756-CFM for Use in a New
An existing application
Configure a 1756-CFM Module for Use in an
Existing Application on page 152
.
