114 Rockwell Automation Publication 1756-UM010B-EN-P - December 2011
114 Configuring the Configurable Flowmeter Module
5. Use ladder logic and a message instructions to send the new
configuration to your CFM module, see page 89 .
I.Status[0].TotalCounts Decimal DINT Displays actual pulses counted by the counter
connected to the channel 0
I.Status[0].FillTotal Float REAL Same calculation as Net Volume
during fill cycle.
I.Status[0].GrossVolume Float REAL Total Counts during each
Sample/K-factor x Meter Factor as occurs on
channel 0
I.Status[0].NetVolume Float REAL Total Counts during each
Sample/K-factor x MeterFactor x CCF) as
occurs on channel 0
I.Status[0].GrossRate Float REAL Total Counts in Meter Sample/ (K-factor x
Sample Interval) x Meter Factor as occurs on
channel 0
I.Status[0].NetRate Float REAL Total Counts in Meter Sample/ (K-factor x
Sample Interval) x Meter Factor x CCF as
occurs on channel 0
I.Ch0AccelerationAlarm Decimal BOOL Displays whether acceleration alarm was set
on channel 0
0 = alarm was not set
1 = alarm was set
I.Ch0OverspeedAlarm Decimal BOOL Displays whether overspeed alarm was set on
channel 0
0 = alarm was not set
1 = alarm was set
I.Ch0OverrangeAlarm Decimal BOOL Displays whether overrange alarm was set on
channel 0
0 = alarm was not set
1 = alarm was set
I.Ch0OverflowAlarm Decimal BOOL Displays whether overflow alarm was set on
channel 0
0 = alarm was not set
1 = alarm was set
Table 9 - Tag Changes Required for Totalizer Mode Using Filler Function
Name Style Data type Definition Enter
this
Value
