Page 64

Publication 1734-UM003B-EN-P - August 2005
A-6 Configure Modules in RSLogix 5000 Software
Work with the Counter
Configuration Dialog
In Hard Run mode, you disable all controls on the Counter
Configuration dialog, in addition to the enable and disable state for
each control.
Use the following procedures to complete entries from this dialog.
After you select Type, refer to the table to see what other entries are
available in the dialog.
.
These
Entries Are Available
If You Select This For Type
Counter
Encoder
X1, X2, X4
PWM
Period/Rate
Continuous/
Rate
Rate
Measurement
Pulse
Generator
Store Count Mode
X
X
Rollover
X
X
Set to Zero
Counter Attenuator
X
X
X
Frequency Precision
X
X
X
Time Base/Gate Interval
X
X
Invert Input Z
X
X
X
X
X
Scalar
X
X
X
