Page 23: Chapter

background image

1

Publication 1734-UM003B-EN-P - August 2005

Chapter

2

Install the Module

What This Chapter Contains

Read this chapter for information about how to install the modules.

The 1734-VHSC module is a two-module set. Module 1 houses the
1734-VHSC functionality while module 2 provides screw terminals
necessary to access chassis ground (Chas Gnd) and common (C).

Module 2 also connects terminal 4 to 5 and terminal 6 to 7 for ease of
wiring power to the input device. Module 2 is not necessary for VHSC
functionality but eases customer wiring. Module 2 does not use a
node address, and it doesn’t consume power from the POINTBus. To
reduce loop area, place module 2 adjacent (either side) to module 1.

Before You Begin

For Information About How To

See Page

Before You Begin

2-1

Install the Mounting Base Assembly

2-1

Install the Module

2-4

Install the Removable Terminal Block

2-6

Remove a Mounting Base

2-6

Wire the Modules

2-7

ATTENTION

Preventing Electrostatic Discharge

This equipment is sensitive to electrostatic discharge,
which can cause internal damage and affect normal
operation. Follow these guidelines when you handle
this equipment:

• Touch a grounded object to discharge potential

static.

• Wear an approved grounding wriststrap.
• Do not touch connectors or pins on component

boards.

• Do not touch circuit components inside the

equipment.

• If available, use a static-safe workstation.
• When not in use, store the equipment in

appropriate static-safe packaging.
