1–19 Getting Started
1336 FORCE — 5.9 August 1995
Step 4 — Write Links
One node link is downloaded in each block transfer routine. The
same block transfer routine is used in each download, but
information in the data file is changed for each node link that is
transferred. The data in word N57:2 specifies the block and node that
receives the data, while word N57:3 specifies the block and node that
provides the data. Data is entered in hexadecimal format.
— Link the Limit Block Input to the Rate Limit
Output
BTW
Data File
N57:0 0000 8F04 8001 8504 0 0 0 0 0 0
0 1 2 3 4 5 6 7 8 9
1. Link the Limit block Input (block 1, node 0) to the Rate Limit
Output (block 4, node 5).
2. Toggle bit I:00/00 to initiate the block transfer routine which will
download the link.
3. Verify that the write was successful. If N57:101 = 0F04
hex
(Block
Transfer Read data), there are no errors.
— Link the SR FF Block Set to the Limit Max Limit
Flag
BTW
Data File
N57:0 0000 8F04 8002 8301 0 0 0 0 0 0
0 1 2 3 4 5 6 7 8 9
4. Link the SR FF block Set (block 2, node 0) to the Limit Max
Limit Flag (block 1, node 3).
5. Toggle bit I:00/00 to initiate the block transfer routine which will
download the link.
6. Verify that the write was successful. If N57:101 = 0F04
hex
(Block
Transfer Read data), there are no errors.
