Serial Communications B-13
Table B.1 “Display Unit” Equivalent to Parameter Text Descriptions
Parameter
Number Parameter
Name
Text
Display
Unit
5 Freq Select 1 “Remote Pot” 1
6 Freq Select 2 “0-10 Volt” 2
62 Freq Source “4-20 mA” 3
“MOP” 4
“Adapter 1” 5
“Adapter 2 ” 6
“Adapter 3” 7
“Adapter 4” 8
“Adapter 5” 9
“Adapter 6” 10
“Preset 1” 11
“Preset 2” 12
“Preset 3” 13
“Preset 4” 14
“Preset 5” 15
“Preset 6” 16
“Preset 7” 17
“Jog Sel ” ➀ 18
Parameter
No. Parameter
Name
Text
Display
Unit
9 DC Boost Select “Fan Sel #1” 0
“Fan Sel #2” 1
“No Boost” 2
“6 volts” 3
“12 volts” 4
“18 volts” 5
“24 volts” 6
“30 volts” 7
“36 volts” 8
“42 volts” 9
“48 volts” 10
“Break Point” 11
“Run Boost” 12
10 Stop Select “Coast” 0
“DC Brake” 1
“Ramp” 2
“S-Curve” 3
➀ Valid for parameter (62) [Freq Source] only.
