Programming 5-38
Output Configuration Group (continued)
[Analog Out Sel] Parameter # 25 Factory Default “Frequency” [Analog Out Sel]
Parameter Type Read & Write
This parameter selects the value to which the 0-10V DC Units Text Setting ‘‘Frequency” 0 to [Maximum Freq] This parameter selects the value to which the 0 10V DC
analog output at TB2-5 is proportional to.
‘‘Current” 0 to 200% of Rated Drive Output Current) g p p p
‘‘Bus Volts” 0 to Maximum Bus Voltage– 410V/230V Drives
815V/460V Drives
‘‘Power” 0 to 200% of Drive Rated OutputPower
“Output Volts” 0 to Drive Rated Voltage
[Above Freq Val] Parameter # 77 Factory Default 0 Hz [Above Freq Val]
Parameter Type Read & Write Minimum 0 Hz
This parameter sets the level at which Output 1 or Output 2
will transition when [Output 1 Config] or [Output 2
Config] are set to ‘‘Above Freq”. This provides an
indication that the drive is operating above the
programmed frequency value. Units 1 Hz Maximum 400 Hz
NOTE: This parameter can not be programmed
while the drive is running.
[Above Curr Val] Parameter # 142 Factory Default 0 % of Drive Rated Current ➀ [Above Curr Val]
Parameter Type Read & Write Minimum 0 % of Drive Rated Current ➀
This parameter sets the level at which Output 1 or Output 2
will transition when [Output 1 Config] or [Output 2
Config] are set to ‘‘Above Curr”. This provides an
indication that the drive output current exceeds the
programmed value. Units 1% Maximum 150% of Drive Rated Current ➀
➀ The drive rated output current is based on three phase input ratings. See page 5-13 for Single Phase Input Rating instructions.
