A-2
Supplemental Drive Information
Environment
(continued)
Atmosphere:
Important: Drive must not be installed in an area
where the ambient atmosphere contains volatile or
corrosive gas, vapors or dust. If the drive is not going
to be installed for a period of time, it must be stored in
an area where it will not be exposed to a corrosive
atmosphere.
Relative Humidity:
5 to 95% non-condensing
Shock:
15G peak for 11 milliseconds duration (
± 1.0 ms)
Vibration:
0.152 mm (0.006 in.) displacement, 1G peak
Electrical
Voltage Tolerance:
For full power and operating range, see the PowerFlex
700S High Performance AC Drive — Phase II Control
User Manual (Publication No. 20D-UM006…),
Appendix E.
Frequency Tolerance:
47-63 Hz.
Input Phases:
Three-phase input provides full rating for all drives.
Single-phase operation provides 50% of rated current.
Displacement Power Factor:
0.98 across entire speed range.
Efficiency:
97.5% at rated amps, nominal line volts.
Max. Short Circuit Rating:
100,000 Amps symmetrical.
Actual Short Circuit Rating:
Determined by AIC rating of installed circuit breaker.
Motor Lead Lengths:
76 meters (250 feet) total
Control
Method:
Sine coded PWM with programmable carrier
frequency. Ratings apply to all drives (refer to the
Derating Guidelines in the PowerFlex Reference
Manual). The drive can be supplied as 6 pulse or 12
pulse in a configured package.
Carrier Frequency:
2, 3 or 4 kHz. Drive rating based on 4 kHz.
Output Voltage Range:
0 to rated motor voltage
Output Frequency Range:
0 to 400 Hz.
Speed Control:
Speed Regulation - without feedback
0.1% of base speed across 120:1 speed range
120:1 operating range
50 rad/sec bandwidth
Speed Regulation - with feedback
0.001% of base speed across 120:1 speed range
1000:1 operating range
300 rad/sec bandwidth
Torque Regulation:
Torque regulation - without Feedback
± 10%, 600 rad/sec bandwidth
Torque regulation - with Feedback
± 5%, 4400 rad/sec bandwidth
Selectable Motor Control:
Field Oriented Control with and without a feedback
device and permanent magnet motor control.
Stop Modes:
Multiple programmable stop modes including - Ramp,
Coast, and Current Limit.
Accel/Decel:
Independently programmable accel and decel times,
adjustable from 0 - 6553.5 seconds in 0.01 second
increments.
S-Curve Time
Adjustable from 0.5 to 4.0 seconds
Intermittent Overload:
110% Overload capability for up to 1 minute
150% Overload capability for up to 3 seconds
Current Limit Capability:
Proactive Current Limit programmable from 20 to
160% of rated output current. Independently
programmable proportional and integral gain.
Electronic Motor Overload Protection:
Class 10 protection with speed sensitive response.
Investigated by U.L. to comply with N.E.C. Article 430.
U.L. File E59272, volume 12.
Category
Specification
