Appendix
A
Supplemental Drive Information
Specifications
For information on ... See page ...
Specifications A-1
Communication Configurations A-3
Category Specification
Agency
Certification Listed to UL508C and CAN/CSA-C2.2 No. 14-M91.
Marked for all applicable European Directives (1) :
EMC Directive (89/336/EEC)
EN 61800-3 Adjustable Speed electrical power drive systems
Low Voltage Directive (73/23/EEC)
EN 50178 Electronic Equipment for use in Power Installations
The drive is also designed to meet the following specifications:
NFPA 70 - US National Electrical Code
NEMA ICS 3.1 - Safety standards for Construction and Guide for Selection, Installation and
Operation of Adjustable Speed Drive Systems.
IEC 146 - International Electrical Code.
(1) Applied noise impulses may be counted in addition to the standard pulse train causing erroneously high [Pulse Freq]
readings.
Category Specification
Protection Drive 480V
AC Input Overvoltage Trip: 570Vac
AC Input Undervoltage Trip: 280Vac
Bus Overvoltage Trip: 810Vdc
Bus Undervoltage Shutoff/Fault: 305Vdc
Nominal Bus Voltage: 648Vdc
All Drives
Heat Sink Thermistor:
Monitored by microprocessor overtemp trip
Drive Overcurrent Trip
Software Overcurrent Trip:
Hardware Overcurrent Trip: 200% of rated current (typical)
220-300% of rated current (dependent on drive rating)
Line transients: Up to 6000 volts peak per IEEE C62.41-1991
Control Logic Noise Immunity: Showering arc transients up to 1500V peak
Power Ride-Thru: 15 milliseconds at full load
Logic Control Ride-Thru: 0.5 seconds minimum, 2 seconds typical
Ground Fault Trip: Phase-to-ground on drive output
Short Circuit Trip: Phase-to-phase on drive output
Environment Altitude: 1000 m (3300 ft) max. without derating
Maximum Surrounding Air Temperature
without Derating:
IP20, NEMA Type 1: 0 to 40°C (32 to 104°F)
Storage Temperature (all constructions): –40 to 70°C (–40 to 158°F)
