Appendix
B
Adapter Parameters
Appendix B provides information about the DeviceNet adapter
parameters.
The parameters in the adapter are numbered consecutively. However,
depending on which configuration tool you use, they may have different
numbers.
Topic
Page
About Parameter Numbers
Configuration Tool
Numbering Scheme
• DriveExplorer
• DriveTools 2000
• HIM
The adapter parameters begin with parameter 1. For
example, Parameter 01 - [Mode] is parameter 1 as
indicated by this manual.
• Explicit Messaging
• RSNetWorx for
DeviceNet
The adapter parameters are appended to the list of drive
parameters. For example, with a drive with 300
parameters, Parameter 01- [Mode] is parameter 301.
Parameter List
Parameter
No. Name and Description
Details
01
[Mode]
Displays the Single or Multi-Drive operating mode
selected with the jumper on the adapter.
Default:
0 = Single Drive
Values:
0 = Single Drive
1 = Multiple Drive
Type:
Read Only
02
[DN Addr Cfg]
Sets the node address used by the drive after a
reset or power cycle.
This setting is used when all of the adapter DIP
switches are in the CLOSED position (all 0’s).
Default:
63
Minimum:
0
Maximum:
63
Type:
Read/Write
Reset Required:
Yes
03
[DN Addr Act]
Displays DeviceNet node address currently being
used by the adapter.
Default:
63
Minimum:
0
Maximum:
63
Type:
Read Only
