Configuring the Adapter 3-11
Bit 1 of Parameter 30 - [Web Features] protects the configuration of
parameters (names and values) shown in the “Process status” fields on
both the Home page (Single Mode only) and Process Display pop-up
window. By default, this configuration is not protected. To protect the
configuration, set the value of Proc Dsp Cfg Bit 1 to “0” (Disabled). You
can unprotected the configuration by changing Bit 1 back to “1”
(Enabled). For more information about configuring the parameters for
display, refer to the
Configure Process Display Web Page section in
Chapter 9 .
Changes to switch settings and some adapter parameters require that you
reset the adapter before the new settings take effect. You can reset the
adapter by cycling power to the drive or by using the following
parameter:
• Set Parameter 17 - [Reset Module] to Reset Module.
Figure 3.12 Reset Screen on PowerFlex 4-Class HIM (22-HIM-*)
When you enter 1 = Reset Module, the adapter will be immediately
reset. When you enter 2 = Set Defaults, the adapter will set all adapter
parameters to their factory-default settings. After performing a Set
Defaults, enter 1 = Reset Module so that the new values take effect. The
value of this parameter will be restored to 0 = Ready after the adapter is
reset.
Resetting the Adapter
!
ATTENTION: Risk of injury or equipment damage exists. If the
adapter is transmitting control I/O to the drive, the drive may fault when
you reset the adapter. Determine how your drive will respond before
resetting a connected adapter.
Value Description
0 Ready (Default)
1 Reset Module
2 Set Defaults
Reset Module
Parameter: # 017
Ready 0
VALUE LIMITS SEL X
