CIP Objects C-3
20-COMM-R Remote I/O Adapter User Manual
Publication 20COMM-UM004D-EN-P
DPI Device Object Class Code
Instances
The number of instances depends on the number of components in the
device. The total number of components can be read in Instance 0, Class
Attribute 4.
Class Attributes
Hexadecimal Decimal
0x92
146
Instances (Hex.) (Dec.) Device Example Description
0x0000…0x3FFF 0…16383 Host 0 Class Attributes (Drive)
0x4000…0x43FF 16384…17407 Adapter 1 Drive Component 1
0x4400…0x47FF 17408…18431 DPI Port 1 2 Drive Component 2
0x4800…0x4BFF 18432…19455 DPI Port 2 … …
0x4C00…0x4FFF 19456…20479 DPI Port 3 16384 Class Attributes (Adapter)
0x5000…0x53FF 20480…21503 DPI Port 4 16385 Adapter Component 1
0x5400…0x57FF 21504…22527 DPI Port 5 … …
0x5800…0x5BFF 22528…23551 DPI Port 6
Attribute ID Access Rule Name Data Type Description
0 Read Only Family Code BYTE 0x00 = DPI Peripheral
0x30 = PowerFlex 70
0x34 = PowerFlex 700H
0x38, 0x39, or 0x3A= PowerFlex 700
0x40 = PowerFlex 7000
0x48, 0x49, or 0x4A = PowerFlex 700S
0x5A = SMC Flex
0x68, 0x69, or 0x6A = PowerFlex 700VC
0x90 = PowerFlex 753/755
0xA0 = 20-750-xxx Option Module
0xFF = HIM
1 Read Only Family Text STRING[16] Text identifying the device.
2 Read/Write Language Code BYTE 0 = English
1 = French
2 = Spanish
3 = Italian
4 = German
5 = Japanese
6 = Portuguese
7 = Mandarin Chinese
8 = Russian
9 = Dutch
3 Read Only Product Series BYTE 1 = A
2 = B …
4 Read Only Number of Components BYTE Number of components (for example, main control board, I/O
boards) in the device.
5 Read/Write User Definable Text STRING[16] Text identifying the device with a user-supplied name.
6 Read Only Status Text STRING[12] Text describing the status of the device.
7 Read Only Configuration Code BYTE Identification of variations.
8 Read Only Configuration Text STRING[16] Text identifying a variation of a family device.
9 Read Only Brand Code WORD 0x0001 = Allen-Bradley
11 Read Only NVS Checksum WORD Checksum of the Non-Volatile Storage in a device.
12 Read Only Class Revision WORD 2 = DPI
