Using Block Transfer Messaging
5-11
20-COMM-R Remote Adapter I/O User Manual
Publication 20COMM-UM004D-EN-P
SLC 500 Controller
Examples
Examples in this section are provided for SLC 500 Series C controllers with
firmware revision 3.xx and higher, and for SLC 500 controllers all versions.
Block Transfer Data Files for Example Program—Series C Controller
with Firmware Revision 3.xx and Higher
In a series C, firmware revision 3.xx and higher SLC processor, Block
Transfer Read (BTR) and Block Transfer Write (BTW) instructions can be
used. When the length of the Block Transfer is 20 words or higher, the
20-COMM-R adapter knows the Block Transfer is for explicit messages and
not for I/O Block Transfer (Chapter 4). Block Transfer setup is the same for
a 1/4 rack or 1/2 rack configuration. This example is for Rack 1, Group 4
(the upper half rack).
The following set of data files shows a read of drive parameter 1 - [Output
Freq]. The value of parameter 1 is 213 (21.3 Hz).
Request and Control Data to Read Drive Parameter 1 (Hex)
Response and Control Data to Read Drive Parameter 1 (Hex)
The following set of data files shows a write of drive parameter 41 - [Motor
NP Volts]. The value written is 2300 (230.0V AC).
Request and Control Data to Write to Drive Parameter 41 (Hex)
Address
Value (hex)
Description
See Page
N12:0
000A
Length of Message = 10 bytes (A hex)
N12:1
0081
Required Setting
N12:2
000E
Service = Get_Attribute_Single
N12:3
0093
Class = 93 DPI Parameter Object
N12:4
0001
Instance = Parameter 1 (1 hex)
N12:5
0009
Attribute = 09 DPI Parameter Value
Address
Value (hex)
Description
See Page
N13:0
0004
Length of Message = 4 bytes
N13:1
0000
The Message was Successful
N13:2
0000
N13:3
00D5
Response Data = 213 (D5 hex) = 21.3 Hz.
n/a
Address
Value (hex)
Description
See Page
N12:0
000C
Length of Message = 12 bytes (C hex)
N12:1
0081
Required Setting
N12:2
0010
Service = Set_Attribute_Single
N12:3
0093
Class = 93 DPI Parameter Object
N12:4
0029
Instance = Parameter 41 (29 hex)
N12:5
0009
Attribute = 09 DPI Parameter Value
N12:6
08FC
Data = 2300 (8FC hex) = 230.0V AC
n/a
