Install components – Rockwell Automation 20B PowerFlex 700 Drives - Frame 10 Components Replacement User Manual
Page 80

80
Rockwell Automation Publication 20B-IN026B-EN-P - July 2013
Chapter 4
Converter Assembly Component Replacement Procedures
Install Components
1. Use isopropyl alcohol to clean the surface where the new Snubber
Resistor(s) will be installed.
2. Verify that the mounting surface of the new Snubber Resistor(s) is clean. If
not, clean with isopropyl alcohol.
3. Use a 3-inch paint roller or putty knife to apply a thin even coating of the
supplied thermal grease to the mounting surface of the new Snubber
Resistor(s) and install.
4. Install the new Snubber Resistor(s). Torque the mounting screws to
2.9 N•m (26 lb•in).
5. Reconnect all wires for the Snubber Resistor(s).
6. Reassemble remaining components in reverse order.
7. Replace all safety shields and enclosure covers before applying power to the
drive.
From
Wire Color
To
Terminal
Snubber Resistor (R)
Black
Snubber Board (R)
J1
Blue
J2
Red
AC Busbar (R)
Snubber Resistor (S)
Black
Snubber Board (S)
J1
Blue
J2
Red
AC Busbar (S)
Snubber Resistor (T)
Black
Snubber Board (T)
J1
Blue
J2
Red
AC Busbar (T)
