Recommended tools – Rockwell Automation 20B PowerFlex 700 Drives - Frame 10 Components Replacement User Manual
Page 10
10
Rockwell Automation Publication 20B-IN026B-EN-P - July 2013
Preface
Recommended Tools
The following list of tools is provided for your reference to disassemble and
reassemble the drive and components. This list may not include all tools for your
situation. Not all tools are needed for some components. See specific sections for
details.
Description
Torque wrench (metered in N•m or lb•in)
Volt ohm meter
Torque seal or colored marker
Screwdrivers (standard, Phillips, torx
–
various sizes)
Magnetic screwdriver, long
Socket set, metric
Cylindrical pick-up magnet
Pliers, regular and needle-nose
Wire cutters
Isopropyl alcohol and applicator cloth
Nylon tie wraps
3- or 4-inch paint roller with short nap or 3- or 4-inch putty knife (for applying thermal grease)
Pencil
