Rockwell Automation Publication 20B-IN026B-EN-P - July 2013

15

Component Diagrams and Torque Specifications

Chapter 1

Figure 2 - Frame 10 Assembly Busbar Locations

R

L1

S

L2

T

L3

Inverter Assembly

Converter Assembly

Motor Busbars

Lower DC Bus Capacitors (8)

Inverter Assembly Shown With
Stacking Panel Removed

Upper DC Bus Capacitors (18)

Lower Capbus Support

Transitional Busbar Assembly
(4 pcs: DC+ Busbar, DC- Busbar,
Upper Capbus Support, and
Lower Capbus Support)

Upper Capbus Support

AC Busbars (3)

DC- Busbar

DC+ Busbar

U

W

V
