Rockwell Automation 20B PowerFlex 700 Drives - Frame 10 Components Replacement User Manual
Page 68
68
Rockwell Automation Publication 20B-IN026B-EN-P - July 2013
Chapter 3
Inverter Assembly Component Replacement Procedures
5. Reconnect all wires for the Balancing Resistor.
6. Replace all safety shields and enclosure covers before applying power to the
drive.
Wire Color
To
Yellow
Capacitor Busbar (lower 8-bank)
Black
Negative (–)
Blue
CNVT (+)
